Description PA Conference System MP69 Series Amplifier is a PA amplifier series product integrating the equalizer, frequency shift, pre-amplifier and power amplifier. The series provides 4 audio source input ports, 6 microphone input ports, 1 line output port and 4 amplifier output terminals. Among them, the volume of 4 audio source channels can be individually controlled with the channel selection function, the volume of 6 microphones can be controlled independently, and the amplifier output volume can be controlled by the master control. It has 7-band EQ to adjust the output. MP69 series products have 100 V and 70 V rated voltage output, and P1 output. They are divided into four models based on power, including 60W(MP6906), 120W(MP6912), 250W(6925) and 350W(6935). The product is designed according to the requirements of the conference site having no whistling microphone, with the tone loud and clear and the volume adjustable. It is provided with multiple protections, well-found function and stable operating state. It can meet the requirements of conference site for the sound amplification and the background music. Model MP6906 MP6912 MP6925 MP6935 Rated Output Power 60W 120W 250W 350W Output Voltage Regulation From full load to no load,≤3dB MIN. EMF. MIC:≤3mV(Unbalanced input) MIC:≤3mV(Balanced input) LINE:≤300mV Frequency Response 80Hz -16KHz (±3dB) THD ≤0.5 (1KHz, under normal working condition) SNR LINE:≥70dB 7-band EQ 64HZ:±12dB 160HZ:±12dB 400HZ:±12dB 1KHZ:±12dB 2.5KHZ:±12dB 6.4KHZ:±12dB 15KHz:±12dB Protection Function DC, overload, short circuit. Mute Function MIC1 and chime input override other inputs. Phantom Power DC24V Frequency Shift 0-5Hz higher than the input signal frequency Working Power AC220-240V/50-60Hz Rated Power Consumption 120W 250W 500W 650W Package Dimensions (mm) (L×W×H)555×455×185 Machine Dimensions (mm) (L×W×H)430×368×88 Gross Weight 12kg 13.8kg 16.5kg 17.8kg Net Weight 10.2kg 12kg 14.8kg 16kg
