EddyFi Lyft Eddy Current Phased Array Flaw Detector

Description EddyFi Lyft Eddy Current Phased Array Flaw Detector EddyFi Lyft Eddy Current Phased Array Flaw Detector is a common PEC phenomenon, that is, defects smaller than the average area of the probe appear shallower than they actually are. Lyft’s Compensating Wall Thickness (CWT) tool mitigates this phenomenon by measuring the minimum wall thickness of a given region in a C-scan. The CWT tool’s special algorithm isolates the contribution of defects in the A-scan signal to more precisely calculate its minimum wall thickness. Optimized Performance for Wall Thickness and Lift Lyft’s solution includes multiple plug-and-play probe sizes for the right balance between wall thickness and take-off. Capable of 457 mm (18 inch) single-pass coverage in grid mode or high-resolution coded dynamic mode. It supports metal thicknesses of 6–25 mm (0.25–1.0 in), insulation of 0–102 mm (0–4 in), and stainless steel and aluminum weather jackets. CUI assessments have never been faster, increasing overall inspection productivity by a factor of 10. Metal supports up to 100 mm (4 inches) thick, 300 mm (12 inches) thick insulation, and stainless steel/aluminum/galvanized steel weather jacket. They complement array probes in limited access inspections, small pipes, and thick components. SPECS Current EddyFi Lyft Eddy Phased Array Flaw Detector : INSTRUMENT Dimensions (W × H × D) 355 × 288 × 127 mm (14.0 × 11.3 × 5.0 inches) Instrument weight 6.6 kg (14.5 pounds) Number of channels 7 (GA/GDA) Display 26.4 cm (10.4 inches) Multi-touch Non-reflective (AR coating) Anti-fingerprint (oleophobic coating) Chemically strengthened 3 mm (1/8 inch) glass cover Optically bonded LCDs and touch screens Passive black light enhancement Lyft is equipped with advanced automation and algorithms that eliminate operator-specific dependencies, thanks to the power of SmartPULSE technology. Automatically optimizes pulser and receiver parameters (gain, duration, gate timing, filters, etc.). SmartPULSE also adjusts Wall Thickness (WT) measurements to ensure optimal performance and repeatability, while limiting the need for advanced knowledge of pulsed eddy currents. The easy-to-use, multi-touch software also includes several innovative features, including real-time C-scan imaging (grid mapping and dynamic mode), complete wall thickness measurement (ID and OD corrosion), and complete inspection management and reporting. ability. The Benefits of Today’s EddyFi Lyft Eddy Phased Array Flaw Detector Check through thick, fire-resistant insulation Saves on insulation removal costs Real-time imaging for instant results Unmatched productivity with PECA Easy setup with SmartPULSE calibration Highest confidence with advanced analysis tools Tau-scan and PermTool Application Corrosion Under Insulation (CUI) and Fire Resistance (CUF) Insulated pipes and vessels Through aluminum, stainless steel and galvanized steel weather jackets Sc that is safe and in the serviceab corrosion assessment, no need to remove the scale In-service inspection of storage tank annular plates Underwater and splash zone structures Ship deck inspections through tiles and coatings
