Item Description Ports 24×10/100Base-TX autosensing Ethernet ports(all support PoE) 2×Gigabit combo ports (RJ45 and SFP) Port attribute 10/100/1000Mbit/s transfer rate Half-duplex, full-duplex and auto-negotiation Auto MDI/MDIX Standards IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-X ANSI/IEEE 802.3 NWay IEEE 802.3x flow control IEEE 802.3af and IEEE 802.3at PoE PoE MAC 4K Packet forwarding rate 6.55Mpps Switching capacity 8.8Gbps EXTEND mode Disabled: all ports can communicate with each other, and monitoring optimization is disabled. Enabled: downlink ports can only communicate with uplink ports; monitoring optimization is enabled, and transmission distance can be extended to up to 250 meters. Status LEDs Link/Act (steady green): link is normal Link/Act (flashing green): data is being forwarded Link/Act (off): no link PoE (steady orange): the port is powering a powered device properly PoE (off): the port is not connected to any powered device or is not supplying power Power (steady green): AC input is normal Power (off): AC input is abnormal PoE 802.3at/af Max PoE capacity: 400 W Consumption ≤ 450 W AC voltage 100-240 V Operating temperature 0°C-40°C (32°F-104°F) Operating humidity 10%-85% Storage temperature -10°C-70°C (14°F-158°F) Storage humidity 10%-90% Dimensions (W×D×H) 440mm×280mm×44mm (17.3″×11″×1.7″)
