DVR-16CN ED8216TEPR 5MP HYBRID

Description Main Features : 16 CH TVI / CVI / AHD video input 16 CH 5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1 recording 4 CH IPC 4MP / 3MP / 1080P / 960P / 720P recording ( Up To 12 IP Cameras Input) Playback: 16CH simultaneously playback; HDMI 1080P output Backup: USB, IE, CMS; support multi-file, file cutting when backup Pentaplex: live, record, playback, backup and remote operation DHCP, DDNS, PPPoE Network protocol, IE browse and CMS supported Dual stream technology; Multi-user online simultaneously Support PTZ preset and auto cruise, up to 128 presets and 8 cruises Cell phone: iPhone, Android Complete SDK function, easy to integrate with other applications Max HDD: 2 x HDD Specifications : Video & Audio Video Input 16 x BNC (HD TVI / AHD / HD CVI / 960H) IPC Input 4 x IP Camera (Up To 12) Video Output HDMI/VGA/CVBS(SPOT) Audio In 4 x RCA Audio Out 1 x RCA Playback Playback 16CH Search Mode Time slice / Recording Recording Resolution TVI / AHD : 5MP@20fps; 4MP, 3MP, 1080P, 720P, WD1 real time CVI : 1080P, 720P real time Frame Rate (fps) 5MP : 10fps (PAL / NTSC) 4MP / 3MP : 12 fps (PAL) / 15 fps (NTSC) 1080P/720P/WD1: 25 fps (PAL) / 30 fps (NTSC) Frame Rate (IPC) 25fps ( PAL ), 30fps ( NTSC ); 4MP, 3MP, 1080P, 960P, 720P Bit Rate 768Kbps ~ 8Mbps (Per CH) Encode VBR/CBR Record Mode Manual, timer, motion, sensor Alarm Alarm In 4CH Alarm Out 1CH Trigger Events Record, PTZ Move, E-Mail, etc. Mode Manual, sensor, motion, exception Network Ethernet RJ45 10/100/1000Mbps × 1 Protocol TCP/IP, UDP, DHCP, DNS, PPPoE, DDNS Storage Internal HDD SATA × 2, max 8T per HDD External HDD N/A Auxiliary Interface RS485 RS485 × 1, connect to PTZ and keyboard USB USB 2.0 × 1 ( front panel ), USB 3.0 × 1( rear panel ) General Power Supply DC 12V Power Consumption ≤ 15W (without HDD) Working Environment 14℉ ~ 122℉ (-10℃ ~ 50℃), 10%~90% (Humidity) Dimensions 15″ x 10.6″ x 2.04″ (380 × 268 × 52mm) ( W × D × H )
