Rover Combined Field Meter with HEVC (HDTAB5-LITE)

The most easy & Combined Field Meter with HEVC – Automatic, fast & easy to use. DVB T2/C/S2 H265 – HEVC 5” High Brightness 16:9 Display SPECIAL FUNCTIONS • Exclusive patented ROVER AUTODISCOVERY system: automatically detects and selects analog and digital COFDM/QAM TV signals in both measurement and spectrum mode; • Automatically identifies all the signals with digital modulation SAT, TV and CATV; • Automatic Assistant: Signal quality analysis, channel scan memorization; • Barscan TV & CATV function from 10 to 100 channels on one screen. • Buzzer & Noise Margin real time graph for digital signals micro-interruptions; • Reflectometric measurements APP (opt.); • Optical input (opt.); • 2.4 & 5 GHz Wi-Fi analyzer (opt.); • HEVC H265 decoder (opt.); • SATELITE: DiSEqC – SCR & dCSS commands, SAT Finder & SAT Expert functions. • Custom Channel Plans: 25 (199 ch. per plan), Programmable TV, SAT (or combined TV/SAT) by PC or local keyboard; • Loggers: TV, SAT & combined with stop & go function; • SAT Memory Plan: More than 2.000 transponders pre-memorized for world wide satellite; • Free SMART PC interface program and FW upgrades. SPECIFICATIONS: MEASUREMENTS, SPECTRUM ANALYSIS & PICTURES • Frequency Range: TV, CATV & Radio: 30-1.000 MHz; SAT: 700–2.700 MHz. • Frequency Resolution: TV & CATV 25 KHz; SAT: 5 MHZ. • Power range Meas.: TV 35 to 115 dBμV, SAT 5 to 105 dBμV. • Digital Meas: Digital Power, MER (36 to 40 dB max depending on modulation), BER, PER, LDPC, BCH, Noise Margin, MER versus CARRIER. • Measurement Resolution: 0.1 dB. • Level Measurement Accuracy: 1 dB typ. (2 dB max.) • Resolution Filter Bandwidth: TV & CATV: 100 KHz @ -3 dB; SAT: 5 MHz @ -3 dB. • Constellation: for TV/CATV and SAT signals. • Spectrum: Fast spectrum, Max Hold and spectrum memorization with real time compare function. • Net-id on board: Net-id, NID, TSID, LCN, SAT Orbit Position. • Echoes, Pre-echoes, Micro-echoes: Representation in real Time. • Quality: Digital Auto quality Test: PASS-MARGINAL-FAIL. • Digital Pictures: MPEG2-4 SD & HD, HEVC (opt.) pictures with Program List, Audio Video PIDs, LCN, Video bit Rate all on one screen. OPTICAL MEASUREMENTS • SC input connector. • Automatic loss calculation. • Wavelengths (nm): 1310, 1490, 1550. • Range: -25 to 6 dBm. • Resolution: 0.1 dB. • Accuracy: /- 0.5 dB. • Optical to RF conversion. COMM. PORTS AND OUTPUTS • RF Input : 75 ohm (interchangeable “F”). • USB 2.0: Type B (PC Interface). • Audio: AAC supplied, DOLBY (opt.). • Video: Composite Video input. GENERAL SPECIFICATIONS • 5” TFT TOUCH display: 16:9 high resolution and high brightness. • Power Supply: Built in LiPo battery with 2 to 4 hours duration (depending on the function) & Battery Test function. • DC voltage at RF input: 5 – 12 – 18 – 24 V, DC DiSEqC, SCR & dCSS commands. • PC Interface: USB-B. • Front-Panel: Alpha numeric keypad. • Power Save: TFT backlight timer, brightness adj. • PC Management: SMART software. • Weight: only 1,4 Kg with batteries. • Size: H 13,0 x W 25,5 x D 4 cm. • Housing: Aluminium and Steel and padded bag. OPTIONS • Optic Ingress • Decoding HEVC H265 images • Wi-Fi analyzer • Dolby Audio AC3 DD • Elite bag with extra padding NOTE: • All technical features can change without notice; • Some options (APP) must be requested when ordering the instrument; • The screens and the texts of the relative MENU, can change without notice from model to model and according to the SW version installed. SKU: HDTAB5-LITE Categories: DVB, Instruments, Satellite Tags: analyzer, Rover meter
