Description Features Measurement Parameters: Pulse width, distance uncertainty Loss resolution, and min. Distance resolution Connector Options: FC interchangeable adapter Optional: SC, ST, LC adapters Optional OPM: T: 8 dBm to -70 dBm or C: 26 dBm to -50 dBm VFL Output: 1 mW for visual fault location Internal memory with optional TF card 5 in (8.89 cm) TFT color LCD, long-lasting battery Technical specification Dead Zone Event: 4.92 ft (1.5 m) or Attenuation: 16.4 ft (5.0 m) Pulse Width S or A: 5 ns to 10 us, B or C: 5 ns to 20 us, MM to A: 5 ns to 1 us Distance Uncertainty ±(31.5 in (0.8 m) ±0.001% x testing distance resolution) Loss Resolution 0.001 dB Min. Distance Resolution 3.93 ft (0.1 m) Connector FC interchangeable adapter OPM T: 8 dBm to -70 dBm or C: 26 dBm to -50 dBm, only available when OTDR is only one connector Vfl 1 mW Wavelength 1310 nm or 1550 nm Max Distance 37.28 mi (60 km) Dynamic Range 22 dB or 24 dB Connector Type SC, FC, LC, ST Data Storage >1000 traces Internal (TF card is optional) Display 3.5 in (8.89 cm) TFT color LCD Battery Standby >15 hrs, measurement >8 hrs Working Time Built in rechargeable battery
