Fiber Talk Set with Dual Functionality for Testing – GAOTek

Description Overview GAOTek fiber talk set with dual functionality for testing is an intelligent and efficient instrument that combines in one set the functions of both a digital optical phone and a stabilized light source. It is widely used in operations of installation, optical testing, maintenance and fiber attenuation value testing in data networks, CATV, and Telecommunication networks.  It can carry out full-duplex communication with high-quality connection and not be affected by distance. With comfortable hand feelings, and nice outside looking, the user can easily operate on this optical tester.   Technical Specifications Wavelength 1310 or 1550 Emitter Type FP or LD Transmission Distance 49.71 miles (80km) Dynamic Range 40 dB Output Power -5 dBm to -7dBm (9 um or 125 um), CW or 2KHz, 1KHz, 270Hz Modulation Output Stability Rechargeable Battery Power Supply Adaptor Battery Operating Time 5 hours Optical Connector FC or PC Operating Temperature 14°F to 140°F (-10°C to 60°C) Storage Temperature -13°F to 158°F (–25°C to 70°C) Dimension 8.46 in x 4.53 in x 2.17 in (21.5 cm x 11.5 cm x 5.5 cm) Weight  183.42 oz (520 g)
