Description Technical Specifications Distance Range 0.06 mi, 0.3 mi, 1.2 mi, 3.1 mi, 6.2 mi, 12.4 mi, 24.8 mi, 49.7 mi (100 m, 500 m, 2 km, 5 km, 10 km, 20 km, 40 km, 80 km) Optical Port FC or SC Sampling Resolution Minimum 0.65 ft (0.2 m) Sampling Point 64,000 points Linearity ≤ 0.05 dB/dB Loss Threshold 0.01 dB Loss Resolution 0.001 dB Distance Resolution 0.01 m Distance Accuracy ± (0.5 m test distance × 3 × 10 – 5 sampling resolution) (excluding refractive index error) Data Storage More than 40,000 test curves Data Interface 2 USB ports (Type A × 1, Micro usb × 1), SD card Monitor 4.3-in TFT-LCD (standard capacitive touch screen) Battery 3.7 V or 5200 mAh Temperature Working temperature: -14 °F to 131 °F (-10 ℃ to 55 ℃) Storage temperature: -4 °F to 176 °F (-20 ℃ to 80℃) Humidity ≤ 95 % (non-condensing) CPU Frequency 1 GHz, equipped with 1 G DDR and 2 G memory card Dimension and Weight 6.88 in × 4.13 in × 1.77 in (175 mm x 105 mm x 45 mm) 1.1 lb (0.5 kg), with battery Accessories Power adapter, Lithium battery, FC adapter, USB cable, Quick guide, Carrying bag Optical Power Meter Type A: -70 dBm to 10 dBm; Type B: 26 dBm to -50 dBm Stable Light Source Output power: -5 dBm, modulation frequency: CW or 270 Hz or 1 KHz or 2 KHz Visual Fault Locator 10 mW, CW or 2 Hz Network Cable Test Terminal Support network cable sequence test and pairing
