DWDM Transponder With 40 KM Reach And CDR Function-GAOTek
$50.36
$82.09
Description Features Supporting DWDM transmission, wavelength conversion. Supporting up to 40 KM without relay. Supporting multiple client-side service access: QSFP28 (100GBase-SR4/CWDM4/LR4/PSM4). Supporting CDR function, which can optimize output, DDM signal monitoring and ALS (Automatic Laser Shutdown) function. Supporting SNMP-based unified network management platform, network management mode CLI, WEB, NetRiver (graphical interface). Supporting software to close the port. Supporting line-side: CFP or CFP2, coherent and tunable. Technical Specifications Wavelength Range DWDM: C-Band (100 GHZ or 50 GHZ). Tunable. Service Access Types 100 GE, OTU4. Dispersion Tolerance ±40000 ps, nm@100 G ±10000 ps, nm@200 G OSNR Tolerance <12.5 dB@100 G <21 dB@200 G Network Management Functions CDR function (DDM real-time monitoring), ALS (Automatic Laser Shutdown) function, service access one-way or bidirectional setting. Network Management Mode CLI, NetRiver, WEB. Working Temperature 14 °F to 158 °F (-10 ℃ to70 ℃) Storage Temperature -40 °F to 185 °F (-40 ℃ to 85 ℃) Relative Humidity 5 % to 95 % no condensation Product Dimension 177 mm (W) x 40 mm (H) x 225 mm (D) Safety And EMC Compliance with FCC or UL or CE or TUV or CSA standards. Power Consumption <21 W
