50 GHz Mux Demux With Low Insertion Loss And High Isolation – GAOTek
$39.81
$53.74
Description Features 50GHz ITU channel spacing Low insertion loss Multi-channel number High channel isolation High stability and reliability Technical Specifications Number Of Channels 40 or 80 or 96 or other Wavelength Accuracy (nm) ± 0.05nm Min. Channel Passband (@-1dB bandwidth) nm 0.4nm Insertion Loss (dB) < 6.0dB Channel Passband (@-1dB Bandwidth) (nm) > 0.2dB Channel Passband (@-3dB Bandwidth) (nm) > 0.3 dB Total Crosstalk(dB) > 20 dB Channel Ripple (dB) < 0.70 dB Adjacent > 22 dB Non-adjacent > 27 dB Max. Uniformity 1.2 dB Chromatic Dispersion (ps/nm) -20 20 ps/nm Max. Polarization Dependent Loss (dB) 0.5 dB Max. Polarization Mode Dispersion (ps) 0.5 ps Min. Directivity (dB) > 50 dB Min. Return Loss (dB) > 45 dB Maximum Power Handling (mW) 300 mW Fiber Type SMF-28e or other Operating Temperature (°C) 23 °F 158 °F (-5 °C 70 °C) Storage Temperature (°C) -40 °F 85 °F (-40 °C 85 °C) 19″ 1U Rack Mount 16.99 in x 9.84 in x 1.73 in(43.16 cm x 25.00 cm x 4.39 cm)
