JSB 6-Way JSB Power Extension 10M

Design Conductor: solid bare copper AWG23/1 Insulation: Cellular polyolefin  (SFS-PE), nominal Ø 1.38 mm Pair: No 2 insulated conductors stranded together into a pair Colour code: 1. White/blue 2.White/orange 3. White/green 4. White/brown (IEC 708-1) Screen 1: Aluminium/polyester or Aluminium/polyester/aluminium tape over each single pair Screen 2: overall Tinned Copper Wire Braid Outer jacket: Grey Fire Retardant and UV Resistant SHF2 material, LSZH Marking : APS Finland – ww/yy – S/FTP 4x2xAWG23/1 Cat.7 LSZH SHF2 – IEC60332-3-22 Cat A – lot m Environmental properties and Fire Performances Degree of acidity of gases: IEC 60754-1, IEC 60754-2 (pH value ≥ 4,3 and Conductivity ≤10μS/mm) Halogen acid gas: IEC 60754-1, IEC 60754-2 (Halogen acid gas emission ≤ 0.5%) Smoke Emission: IEC 61034-2, EN 50268-2 (Transmittance) ≥ 60%) Toxicity of evolved gas: EN50305 9.2 Flame retardant : IEC 60332-1-2 Fire retardant : IEC 60332-3-22 Cat.A Ozone resistant: IEC60811-2-1, DIN VDE 0472 part 805 B LSZH SHF2 : IEC 60092-360 Oil resistant: IEC60811 Water absorption: IEC60811-1-3 UV resistant: IEC60811-2-1, ASTM-D-2565-92A Cold bend & impact : CSA C22.2, UL44 Electrical characteristics (IEC 60811, EN 50288-4-2) Test voltage:  0.7kV a.c. for 1 minute Resistance of the conductor @ 20°C : ≤ 14,5 /100m Insulation resistance : ≥ 500 MΩxkm (100V-500V) Nominal Capacitance @ 800÷1000MHz : 45 pF/m Average characteristic impedance: 100 ± 15 Ω @ 1-100MHz Transfer impedance : ≤ 3mΩ/m @ 10MHz
