Dual Channel FFT Vibration Spectrum Data Collector and Analyzer – GAOTek

Description Features It captures both waveform & FFT spectrum for two channels—good for comparing two sensors or two measurement points at once. Spectrum span choices up to 10 kHz let you examine mid- to high-frequency vibrations (bearings, gears etc.). 100-400 line resolution with Hanning windowing gives decent clarity—not ultra high resolution like lab-grade, but solid for field diagnostics. Storage of 1024-point data means you can record rich snapshots, do post-processing later. USB transfer means you’re not stuck manually reading; you can move data to PC for deeper analysis. Used for dynamical balancing, fault diagnosis, site vibration measurement.   Technical Specifications Specification Details Number of Channels 2 simultaneous vibration channels Measurements / Analysis Modes FFT spectrum display, waveform display, transfer function analysis Frequency Span (“spectrum span”) 100 Hz, 200 Hz, 500 Hz, 1 kHz, 2 kHz, 5 kHz, 10 kHz Lines of Spectrum (Resolution) 100 to 400 lines, using Hanning window Sampling / Data Points 1024-point time records (per channel) Data Storage Stores waveform spectrum data Display On-device display of waveform spectrum Output / Interface USB interface for data transfer Application / Use Case Machinery diagnostics, dynamic balancing, site vibration monitoring
