Planet POE-2400G 24-Port Gigabit IEEE 802.3at PoE Managed Injector Hub (440 watts) Introducing the PLANET POE- 2400G Managed PoE Injector Hub Series – a cost-effective and rapid Power over Ethernet (PoE) solution designed to seamlessly upgrade existing network infrastructures to IEEE 802.3at Power over Ethernet Plus network systems, all without the need to replace the current Ethernet Switch. The Planet POE-2400G is a feature-rich, high-density, and rack-mountable managed IEEE 802.3at PoE injector hub, equipped with PLANET’s intelligent PoE functions accessible through a user-friendly web interface for remote management. Living up to its name, this unit boasts a total PoE budget of 440 watts, making it capable of delivering substantial power to Powered Devices (PDs). Each of its 24 10/100/1000BASE-T Ethernet ports can supply up to 36 watts of power over standard Cat.5/5e/6 Ethernet UTP cables, facilitating simultaneous data and power transmission to remote 802.3at/af powered devices (PDs). With the POE-2400G, centralizing the power supply becomes a reality, optimizing the installation and power management of remote network devices. This hub provides a swift, secure, and cost-effective Power over Ethernet network solution, making it a perfect fit for both small businesses and enterprises. The POE-2400G provides the easiest way to power your Ethernet devices such as IP camera on the ceiling and the wireless access point installed on the top of the building. With 24 10/100/1000BASE-T Gigabit Ethernet ports, the POE-2400G supports full 52V DC power for any remote IEEE 802.3af/802.3at powered device (PD). To control the power system of your networking devices, the POE-2400G can directly co-work with PoE IP phone to build VoIP telephony network in the office. Furthermore, the POE-2400G can be directly connected to any third-party IEEE 802.3af/802.3at compliant devices installed within 100 meters. Upgrade your network infrastructure effortlessly with the PLANET POE Managed PoE Injector Hub Series – a powerful and reliable solution that simplifies PoE deployment without requiring extensive changes to your existing network setup. Key Features Interface 24-port 10/100/1000Mbps “Data input” 24-port 10/100/1000Mbps “Data Power output” One 10/100/1000BASE-T management port Power over Ethernet Complies with IEEE 802.3at Power over Ethernet Plus mid-span PSE Up to 24 IEEE 802.3at/802.3af devices powered 440-watt PoE budget Supports PoE power up to 30.8 watts (802.3at PoE )/15.4 watts (802.3af PoE) for each PoE port Automatically detects PD Circuit protection prevents power interference between ports Remote power feeding up to 100m PoE Management Total PoE power budget control Per port PoE power schedule PoE function enable/disable Per port PoE function enable/disable PoE port power feeding priority PD classification detection Over temperature protection PD alive check Management Web interface for remote management Supports Network Time Protocol (NTP) Firmware upgrade through Web interface PLANET Smart Discovery utility automatically finds PLANET devices on the network SNMP trap for alarm notification of events System log/remote syslog Hardware 19-inch rack mountable; 1U height Reset button for resetting to default setting and system reboot LED indicators for PoE ready and PoE activity LED indicators for power alert and fan alert Specifications Hardware Specifications Details Hardware Version 5 Interface “Data” Input Ports: 24 x RJ45 “Data Power” Output Ports: 24 x RJ45 Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX Data Rate 10/100/1000Mbps LED System: SYS PWR x 1 (Green) PoE Failure x 1 (Red) Fan1 Failure x 1 (Red) Fan2 Failure x 1 (Red) Per PoE Port: PoE-in-use x 1 (Green) Management port x 2: 1000 (Green), 10/100 (Orange) Network Cable 10BASE-T: 4-pair UTP Cat5 up to 100m (328ft) 100BASE-TX: 4-pair UTP Cat5 up to 100m (328ft) 1000BASE-T: 4-pair UTP Cat5e/6 up to 100m (328ft) EIA/TIA- 568 100-ohm STP (100m) Power Requirements 100-240V AC, 50/60 Hz, 8A Power Consumption 500 watts (max.) Dimensions (W x D x H) 440 x 300 x 44mm Ventilation Fan x 2 Power over Ethernet Details PoE Power Supply Type Mid-span PoE Power Output Per port DC 52V 30.8/15.4 watts Power Pin Assignment 4/5( ), 7/8(-) PoE Power Budget 440 watts@0~40 degrees C 400 watts@41~50 degrees C Auto power budget control by over temperature protection function Number of 802.3af PDs (Class 0, 1, 2, 3) can be powered 24 Number of 802.3at PDs (Class 1, 2, 3) can be powered 14 Number of 802.3at PDs (Class 0, 4) can be powered 14 Management Details Management Interface Web, PLANET Smart Discovery Lite PoE Management Power limit by consumption and classification mode PoE admin mode Per port power schedule Per port power enable/disable Power feeding priority Over temperature protection Current per port usage and status Total power consumption Management Feature Setup of system/management functions Web firmware upgrade SNMP trap for alarm notification of events Standards Conformance Details Regulatory Compliance FCC Part 15 Class A, CE Standards Compliance IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3af Power over Ethernet RFC 768: UDP RFC 791: IP RFC 2068 HTTP RFC 1157: SNMP v1 RFC 1902: SNMP v2c RFC 5424: Syslog Environments Details Operating Temperature: 0 ~ 50 degrees C Relative Humidity: 5 ~ 90% (non-condensing) Storage Temperature: -10 ~ 70 degrees C Relative Humidity: 5 ~ 90% (non-condensing)
