Description Technical Specifications CPU Industrial 32 bits CPU FLASH 16MB (Extendable to 64MB) SDRAM 128MB Serial 2 RS232 ports (or 1 RS232 and 1 RS485), 15 KV ESD protection Serial port 8PIN industrial terminal, 3.81mm pitch Data bits 5, 6 ,7, 8 Stop bits 1, 1.5(optional), 2 Parity none, even, odd, space, mark Baud rate 110~230400 bps Large serial port data cache10MB LAN 1 10 or 100Mbps Ethernet ports (RJ45), auto MDI or MDIX, 1.5K V magnetic isolation protection Antenna Standard SMA female interface, 50 ohms SIM/UIM Standard 3V or 1.8V user card interface, 15KV ESD protection Power Terminal block interface, reverse-voltage and over voltage protection Reset Inside the module. Press this key for 8 seconds to restore the module to its original factory default settings Wireless Network GSM or GPRS or EDGE 850 or 900 or 1800 or 1900MHz CDMA 800 or 1900MHz WCDMA or HSUPA or HSPA 850 or 900 or 1900/ or 100MHz CDMA2000 1x or EVDO Rev. 800 or 1900MHz TD-SCDMA 1880 to 1920 or 2010 to 2025MHz (A orF) TDD-LTE Band 38 or 39 or 40 or 41 and Band 61 or 62 (Private Network) FDD-LTE Band or or 2 or 3 or 4 or 5 or 7 or 8 or 12 or 13 or 17 or 18 or 19 or 20 or 21 or 25 or 26 or 28 or 66 PPP Protocol Support PPP Protocol PPP Heartbeat Maintaining links with the cellular network to prevent forced sleep, to ensure the stability of dial up link. Network Authentication Support CHAP or PAP Authentication TCP Heartbeat Monitor the server connection Power range DC 5 to 60 V, Recommended 12 VDC Communication Current <410 mA (at 12V DC) Standby Current <250 mA(at12VDC) Shell Material ABS Operating Humidity 95% (unfreezing) Dimensions 4.26 in x 3.34 in x 1.60 in (108.43 mm x 85 mm x 40.7 mm) Weight 4.44 oz(126 g) Operating Temperature -31 ºF to 167 ºF (- 35 ºC to 75 ºC) Storage Temperature -40 ºF to 185 ºF (- 40 ºC to 85 ºC)
