Cat 8 STP Foldable Patch Panel

Briticom® Cat 8 STP Foldable Patch Panel offers a perfect solution for high-density applications. It has a professional v-design 24 or 48-ports and is foldable for better patch cord management. As the panel is angled you can manage 12 patch cords easy from both sides, so there is a better cable management inside of the rack. Already bought this product from us? Share your experience on LinkedIn. FEATURES APPLICATIONS TECHNICAL DATASHEET V-Design for better patch cord management 24 or 48 modular ports Available in 1U, 0.5U, and with shutters For use with Cat 8.1 keystone module with 360° shielding supports transmission speeds of up to 25 GBit/s or 40 GBit/s in connection with Cat 8 installation cables with 2000MHz In connection with a modular patch panel, the Cat 8 keystone modules are perfect for future-oriented, structured building cabling The mounting connection of the keystone module of the Category 8 Class 1 makes the tool-free installation of the network cable (AWG 22-26) possible – cable fixation is done with a cable tie Cable installation via LSA strips, colour coded according to ANSI/TIA-568-C.2:2009 & ANSI/TIA-568.0-D:2017 Tool-free mounting connection Data & Server Racking Patch Panel Housing material 1.5 mm SPCC cold rolled steel sheet, powder-coated Grounding Central ground connection   KSJ Transmission properties Category 8, Class I Area of application Up to 2000 MHz, 25/40GBase-T Norms ISO/IEC 11801 3rd Ed., EN 50173-1, ANSI/TIA-568-C.2:2009, ANSI/TIA-568.0-D:2017, 802.3af, 802.3at, 8023.bt (PoE, PoE , 4PPoE) Housing material Zinc die-cast, nickel-plated RJ45 female contact Tinned phosphor bronze, 50um gold-plated contact IDC termination clamp Krone LSA , UL 94V-2, zinc plated phosphor bronze Insertion force 30N max. (IEC 60603-7-5) Retention strength 7.7 kg between jack and plug Operation temperature -10° C to 60 °C Clamp > 200 acc. to ISO/IEC 11801, IEC 60603-7-5 IDC wire size 22 – 26 AWG solid and stranded conductor Insulation resistance > 500 MOhm Colour Silver Suitable for flat cable No Cat 8 STP Foldable Patch Panel DOWNLOAD DATASHEET
