12V IoT Gateway VPN Router with Industrial CPU, WLAN, and Cellular – GAOTek
$54.79
$97.53
Description Overview GAOTek industrial router is a kind of terminal device developed based on 2G/3G/ 4G, WIFI, and VPN technology. It adopts a high-powered industrial 32-bit CPU and embedded real-time operating system. It supports RS232 (or RS485), Ethernet and WIFI ports that can conveniently and transparently connect one device to a cellular network, allowing it to connect to your existing serial, Ethernet and WIFI devices with only basic configuration. Technical Specifications Items Contents Hardware System CPU Industrial 32 bits CPU FLASH 16 MB (Extendable to 64 MB) SDRAM 128 MB Interface WAN 1 10 or 100 Mbps WAN port(RJ45) LAN 1 10 or 100 Mbps Ethernet ports(RJ45) Serial 1 RS232 or RS485 or RS422 port Antenna Cellular: Standard SMA female WIFI: Standard SMA male Network Wireless Network GSM or GPRS or EDGE: 850 or 900 or 1800 or1900MHz WCDMA or HSUPA or HSPA : 850 or 900 or 1900 MHz or 2100 MHz TDD-LTE: Band 38 or 39 or 40 or 41 & Band 61 or 62 FDD-LTE: Band 1 or 2 or 3 or 4 or 5 or 7 or 8 or 13 or 17 or 20 or 25 or 28 or 66 WIFI Standard IEEE802.11b or g or n Bandwidth IEEE802.11b or g: 54Mbps (max) IEEE802.11n: 150Mbps (max) Power supply Standard Power DC 12 V or 1.5 A Power range DC 5 V to 35 V Physical Dimensions 5.35 x 3.89 x 1.10in (136x99x28mm) Weight 0.8 lbs (395 g) Temperature Operating Temperature -35 ℉ to 167 ℉( 75 ºC) (-31 ℉ to 167 ℉)
