Description Technical Specifications Frequency Range 9 KHz to 20 GHz Frequency Accuracy ± 0.01 ppm Level Accuracy ± 1.5 dB Level Resolution 0.1 dB Phase noise -114 dBc or Hz at 10 KHz Offset at 1 GHz, -115dBc or Hz at 100 KHz Offset at 1 GHz, -131dBc or Hz at 1 MHz Offset at 1 GHz Reference level range -130 dBm to 30 dBm Maximum input safe power 25.7 dBm Second harmonic suppression -75 dBC Third order intermodulation 12 dBm (typical value) Remaining Response -90 dBm Standing wave ratio 2.0 Spectrum scanning speed 9 kHz to 6.3 GHz: 18 GHz or s at 25 KHz .9 kHz to 9 G or 20 G: 137 GHz or s at 25 KHz Real time spectrum analysis bandwidth Maximum 100 MHz Demodulation analysis support mode SG-NR, LTE, NB-IoT, WCDMA, GSM, Vector Power Supply AC100 V to 240 V or 50 Hz to 60 Hz DC12 V Ambient Temperature 32 ℉ to 104 ℉ (0 ℃ to 40 ℃) Display 10.5 in (26.6 cm) high-definition display screen Size 11.6 in x 8.8 in x 1.9 in (295 mm x 225 mm x 50 mm) Weight 5 lb (2.3 kg)
